Sale of - Picanol OmniPlus-i Connect
Picanol OmniPlus-i Connect
Dettagli
- Brand: Picanol
- Model: OmniPlus-i Connect
- Year: 2021
- Technology: weaving
Picanol OmniPlus-i Connect
Gallery
Technical Specifications
General information
- Rpm : 1100
- Width : 3400
Machine specifications
- Machine status : working
- Voltage : 380
- Frequency : 50
- Fabric type : High-end Home Textiles and Upholstery
- Movement type : jacquard
Jacquard details
- Jacquard year : 2021
- Jacquard brand : Stäubli
- Jacquard model : LXL
- Density : 565
- Colors : 6
- Frames : 0
- Healds : 4800
- Structure type : double
- Droppers : 12000
- Total capacity hooks : 5376
- Lower beams : 1.5
- Upper beams : 1.0
- Weft feeders : 4
- Batching motion : Sì
- Number of pavilion : 566
- Gantry type : quadruple
- Includes cloth roller : Sì
- Installed hooks : 4800
- Include gantry : Sì
- Include harness : Sì
- Quantity of cloth rollers : 1
- Include structure : Sì
- Controller brand/model : Stäubli JC8
- Lower flange diameter : 1000
- Upper flange diameter : 800
Loom accessories
- Colors : 5
- Frames : 4
- Healds : 8
- Droppers : 800
- Weft feeders : 4
Beams and rollers
- Lower beams : 1.0
- Upper beams : 1.0
- Lower flange diameter : 800
- Upper flange diameter : 800
Video Demonstration
Additional Information
El lote consta de 4 unidades Picanol OmniPlus-i Connect en estado impecable, configuradas específicamente para la producción de tejidos Jacquard de alta complejidad para decoración de interiores. Cada máquina incluye la tecnología BlueBox de Picanol para optimización electrónica y el sistema Sumo de accionamiento directo.
